Detail Item- Concrete Slab Edge Rebate over Waffle Pod (Section)

$0.00

This is a section detail showing a typical slab edge rebate with a waffle pod construction. This is a Revit 24 family.

Installation

Unzip the folder to the selected path, right-click to select Extract Here.

How to Load Revit Family

1. Open Revit, Open Revit family or insert into project

2. Select types required from type list.

We hope you find this family valuable, and that it becomes a useful tool that grows within your firm.
